The new Testo 316-3 heated diode refrigerant leak detector, delivers optimal sensitivity to all CFC, HCFC, and HFC refrigerants, detecting small leaks. By design the 316-3 is resistant to contaminants such as rust, dirt and oil. Productivity features allow users to decrease sensitivity to pinpoint leak sources compensating for refrigerant buildup or pooling allowing the service technician to quickly locate even the smallest leaks. www.trutechtools.com/Testo316-3esto316-3
Key features:
Heated diode sensor technology, sensitive to leaks as small as 0.15 oz/yr (4 g/yr)
Simple one-button operation
Progressive LEDs that illuminate to indicate leak size
Audible alarm
High-/low-sensitivity adjustment
Automatic adjustment to background levels of refrigerant
Rugged Flexible probe
Foam filter for sensor protection
General technical information:
Detectable Refrigerants R 22, R134a, R-404A, R-410A, R-507, R438A and all CFC, HFCs and HCFCs
Certifications SAE J1627, EN 14624, EC 2004/108/EC
Operating temp. -4 to 122° F
Operating humidity 20... 80% RH
Charging Temp. 32 to 104 °F
Battery type 2 x D cells
Battery life 16 hours continuous operation
Lifetime of sensor approx. 80... 100 h (corresponds to approx. 1 year)
Weight @ 1.1 lbs (incl. batteries)
Warranty 2 years
