Daikin indoor units with low capacity

(0) (38)
25 November 2011
Two types of ‘15 class’ indoor units are available: a cassette FXZQ-M9 600x600 with compact casing to fit flush into standard European false ceilings without the need to cut ceiling tiles, and a slim concealed ceiling unit FXDQ-P7 that blends unobtrusively into the interior décor, with only the grilles visible.
‘15 class’ units allow the optimum selection of indoor units in applications with small heating and cooling loads per room such as well-insulated or smaller areas. It will also be possible to connect more indoor units to a single outdoor unit.


Concealed ceiling units FXDQ-P7 are new devices of this year. Compact dimensions make it easily possible to mount them in a ceiling void of only 240mm.
The unit blends unobtrusively with any interior décor: only the suction and discharge grilles are visible. Medium external static pressure facilitates unit use with flexible ducts of varying lengths. Standard air filter removes airborne dust particles to ensure a steady supply of clean air. The units have standard drain pump with 750mm lift. For multi tenant applications an optional PCB is required. Noise level of a FXDQ15P7 unit makes 27 dBA, air flow is up to 450 m3/h.
