KABT fans

601 0
02 March 2012

Новости по теме:

Soler&Palau launched the manufacturing of backward curve centrifugal fans KABT Series. The product range consists of four models with air flow from 2750 m3/h to 11400 m3/h. Cabinet fans manufactured from galvanised steel sheet with double thickness side panels internally lined with 25 mm thickness of fireproof fibreglass acoustic insulation (M0). Circular duct connectionflange on the inlet. KABT incorporates direct drive backward curved centrifugal impeller with motor fitted outside of the air stream. Three phase motor IP55, Motor has 4 poles. Electrical supply - 3 phree phase motor 230/400V-50Hz, speed controllable by inverter and by voltage (KABT-12000 model).
Working temperature from -20ºC to 100ºC.


Cabinet fans are manufactured from galvanised steel sheet with double thickness side panels internally lined with 25 mm thickness of fireproof fibreglass acoustic insulation (M0). Circular duct connectionflange on the inlet. KABT incorporates direct drive backward curved centrifugal impeller with motor fitted outside of the air stream. Three phase motor IP55, Motor has 4 poles. Electrical supply - 3 phree phase motor 230/400V-50Hz, speed controllable by inverter and by voltage (KABT-12000 model).
Working temperature from -20ºC to 100ºC.
Backward curved centrifugal impellers to prevent accumulation of dirtiness are dynamically balanced. Quality finished plastic corners and aluminium profile, providing a great robustness IP55 remote terminal box makes the installation easy and allows connection to external controls.
