Danfoss Ultrasonic Compact Energy Meter

(0) (41)
06 August 2012


Sonometer 1100 - Ultrasonic Compact Energy Meter appeared on the Russian market.
The Sonometer1100 is an ultrasonic static compact energy meter especially designed for heating, cooling or combined heating/cooling application in local and district energy systems.

The Sonometer1100 as a compact energy meter consists of the following components:

    Ultrasonic flow sensor
    Calculator with integral hardware and software for measuring flow rate, temperature and energy consumption
    Pair of temperature sensors

Features:

    1st. approval in Europe for ultrasonic energy meter with dynamic range of qi/qp 1 : 250 in class 2 (qp 1.5 / 2.5 / 6 / 10 / 15 / 25 / 40 / 60 m³/h)
    Complete dynamic range: ≥ 1 : 1500
    Lithium battery, 230 V AC or 24 V AC mains unit
    Battery lifetime 11 years (16 years optional)
    Patented free- beam principle
    Improved service-friendly energy meter design
    Housings with thread and flange (PN 16 / 25)
    Can be configured for heating, cooling or combined heating/cooling application
    Temperature range: 5 - 130 / 150 °C
    Overload temperature up to 150 °C (qp = 0.6 - 2.5 m3/h)
    Swirl-free flow around reflector
    Lower pressure loss
    Robust stainless steel reflector
    Insensitive to dirt
    Available in nominal sizes qp 0.6 / 1.0 / 1.5 / 2.5 / 3.5 / 6 / 10 / 15 / 25 / 40 / 60 m³/h
    Measuring accuracy meets the requirements of EN 1434 (MID) class 2 and 3
    No calming sections necessary in the inlet and/or outlet (standard installation)


Special Features:

    Power save mode
    NOWA test capability
    Remote reading via M-Bus, L-Bus, RS 232, RS 485, Radio or optical interface
    Integrated Radio (868 or 434 Hz), Real Data or Open Metering Standard (OMS)
    Individual remote reading (Automatic Meter Reading) with add on modules Plug&Play
    2 communication ports (e.g. M-Bus + M-Bus)
    Improved radio performance
    Individual tariff functions
    History memory for 24 months
    Extensive diagnostic displays IZAR@SET parameterization software on Windows basis guarantees optimum adaptation to the user's specific needs
