New refrigerant leak detector

(0) (58)
25 October 2012

The new Testo 316-3 heated diode refrigerant leak detector, delivers optimal sensitivity to all CFC, HCFC, and HFC refrigerants, detecting small leaks. By design the 316-3 is resistant to contaminants such as rust, dirt and oil. Productivity features allow users to decrease sensitivity to pinpoint leak sources compensating for refrigerant buildup or pooling allowing the service technician to quickly locate even the smallest leaks. www.trutechtools.com/Testo316-3esto316-3
Key features:

    Heated diode sensor technology, sensitive to leaks as small as 0.15 oz/yr (4 g/yr)
    Simple one-button operation
    Progressive LEDs that illuminate to indicate leak size
    Audible alarm
    High-/low-sensitivity adjustment
    Automatic adjustment to background levels of refrigerant
    Rugged Flexible probe
    Foam filter for sensor protection

General technical information:

    Detectable Refrigerants R 22, R134a, R-404A, R-410A, R-507, R438A and all CFC, HFCs and HCFCs
    Certifications SAE J1627, EN 14624, EC 2004/108/EC
    Operating temp. -4 to 122° F
    Operating humidity 20... 80% RH
    Charging Temp. 32 to 104 °F
    Battery type 2 x D cells
    Battery life 16 hours continuous operation
    Lifetime of sensor approx. 80... 100 h (corresponds to approx. 1 year)
    Weight @ 1.1 lbs (incl. batteries)
    Warranty 2 years
