Fantini Cosmi programmable thermostat

(0) (74)
21 August 2012

Weekly programmable thermostat with integrated GSM. IntelliComfort CH140GSM is manufactured by Fantini Cosmi.

Weekly programmable thermostat to control heating and air conditioning systems, with the remote control possibility via SMS or through specific programs for Smartphone, Android e iOS.

Large display with graphical icons combined with 6 front keys, provided with blue backlighting and writing displayed in dark blue colour, which ensure a modern and technological aesthetics.

Daily operation profile according to the selected temperatures can be visualized by means of histogram.

By sending simple SMS or from applications it is possible:

- to control the home temperature,
- to program the home temperature,
- to receive notification about changes of the two alarm contacts status (e.g. a boiler
alarm, an antitheft alarm, a low temperature alarm) ,
- to turn on or off an external user, such as an irrigation system.

• Operating modes:
AUTOMATIC - weekly program
MANUAL - manual program
HOLIDAY - daily program
JOLLY - temporary program
OFF - system is turned off or with antifreeze program
DAY, COPY and JOLLY functions.

Wall mounting, distance between fixing holes 60 and/or 83,5 mm. Power supply: 230V-50Hz. Keyguard password. 2 auxiliary inputs for alarms (dry contacts). 1 auxiliary relay output (dry contacts), user-programmable. 1 remote temperature probe input. GSM SIM-card in compliance with the standard GSM 11.12 phase 2+ (all SIM-cards except for H3G USIM). Blue LED backlight. Dimensions: 137 x 90 x 32 mm. Maximum power consumption: 10W. Contact rating: 5(3)A 250Vac.
